Forage Harvester

Forage harvesters are used for harvesting every kind of green fodder and grass in order to feed the animals directly or for making silage. The free floating knives on the rotor are specially designed in order to prevent the damage to the machine when they hit a hard material like stones in the field. The rotating speed of the rotor and knives create the blow needed to blow the cut grass to the trailer. The height adjustment can be easily controlled by the spring controlled adjusting pin on the chassis. There is an automatic attachment between chassis and machine in order to connect the machine to the chassis easily by the driver of the tractor.


  • Resistant and long life transmission
  • Evacuation chimney with hydraulic system that can rotate 170º
  • Cap height adjustment with hydraulic system
  • Hydraulic system cutting height adjustment
  • Connection with draw through arrow system and easy progressing feature



AT-MS 130

Lenght mm 2600
Width mm 2150
Height mm 3150
Weight kg 620
Working Width mm 1300
Working Capacity Ton/h 17-18
Number of Blades pcs 21
Required power hp 45
P.T.O Speed rpm 540
Working Speed km/h 8-10
