Traditional Plow

The heavy moldboard plow is made from a blade frame with optional 2-3-4-5-6 holes in widths of 11-12-13-14-16 inches. Our plows are made of quality materials and have a long service life. The suspension system of the truck complies with international standarts and can be connected to any type of tractor. Thanks to the special spring relief mechanisms placed on each body, the plow cannot be damaged by getting rid of all kinds of obstacles on stony ground. The machine is economical in terms of time and fuel.

Description

TECHNICIAL SPECIFICATIONS		ASP11	ASP12	ASP13	ASP14	ASP16	ASP18
Chassis Height		67	67	68	68	70	72
Chassis Depth		74	77	79	79	84	90
Width Working		28	30	32	35	40	45
Depth Working		28	30	32	35	37	40
Weight (2)	kg	215	220	235	245	270	300
Weight (3)	kg	320	352	360	370	410	430
Weight (4)	kg	500	520	535	545	570	600
Weight (5)	kg	615	630	650	660	720	800
Required Power(2)	hp	35-45	45-55	50-55	55-65	60-70	65-75
Required Power(3)	hp	50-60	55-65	60-70	65-75	70-80	80-85
Required Power(4)	hp	65-70	65-75	70-80	75-85	80-90	85-95
Required Power(5)	hp	75-80	80-85	85-90	90-95	100-110	115-130
